| Model ID | Model Name | DOE Htg. Capacity MBH | IBR MBH | Firing Rate GPH | AFUE | Tankless Draw GPM | Tankless Coil No. | Vent Size | Water Content | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| 28653 | WTGO-3 | 115.0 | 100.0 | 0.95 | 85.3 | 3.25 | WT-14 | 7 | 14.9 | 540 |
| 28654 | WTGO-3L | 114.0 | 99.0 | 0.95 | 84.5 | 3.00 | WT-14 | 7 | 14.9 | 595 |
| 28655 | WTGO-4 | 145.0 | 126.0 | 1.20 | 85.0 | 3.75 | WT-14 | 7 | 13.4 | 645 |
| 28656 | WTGO-5 | 175.0 | 152.0 | 1.45 | 85.0 | 4.00 | WT-14 | 7 | 15.9 | 760 |
| 28657 | WTGO-6 | 212.0 | 184.0 | 1.75 | 85.0 | 4.25 | WT-14 | 7 | 18.4 | 860 |
| 28658 | WTGO-7 | 242.0 | 210.0 | 2.00 | 85.0 | 5.50 | WT-20 | 7 | 20.8 | 930 |
| 28659 | WTGO-8 | 266.0 | 231.0 | 2.30 | 5.75 | WT-20 | 7 | 23.3 | 1030 | |
| 28660 | WTGO-9 | 295.0 | 257.0 | 2.55 | 6.00 | WT-20 | 7 | 25.8 | 1135 |
